Model SR-4400


Kategori : General Slip Ring
Marka : MTC
Sipariş Kodu : R0X11-1097
Ürün Adı : Model SR-4400

Model SR-4400


MTC : General Slip Rings Series



The SR-4400, a high accuracy 80-channel Slip-Ring, was especially designed for high quality current and signal transmission under harsh environmental conditions, when a large number of circuits in a compact design isneeded. The outstanding raw materials used for the SR-4400 endow it with extended lifetime, a vital advantage in this type of application. Without casing- case can be designed upon request, according to customer specification.





Specifications :

Parameter

Unit

Value

Number of channels (Circuits)

Circ.

80

Operating Speed

RPM

190

Lead Wire Length

Mm

300

Lead Wire Size (Types)

AWG

30

Total current rating

A

2

Temperature range

C

-45 - +125

Insulation resistance

500
